Details
AM200S mortar grinder is a classic mill , It roots in traditional manual grinding , Simple and convenient operation。Soft, hard, brittle and pasty samples can be ground。The digital display speed can make the grinding result repeatable。Samples that are difficult to grind by heating, freezing or adding grinding aids
Application field
Nut, Quartz, Ceramic tile, Medicine, Soil, Yeast cell, Glass
Performance advantage
• Dry、wet、freezing
• The samples were homogenized by the classic mild grinding method.
• Digital time display ensures repeatability of results.
• The adjustment of the pressure and position of the pestle and the adjustment of the scraper board ensure the optimal grinding state
• Mortar and pestle are plugged structure, no tools, easy to disassemble and easy to clean.
•The instrument has an observation window, and the LED lamp in the grinding chamber can clearly understand the grinding state at any time.
•The control panel has a load display function.
•7different grinding set materials
•Closed, dust-tight grinding chamber
•The instrument has a sensing device , operation safety
Technical information
|
Technical parameter |
Mortar grinder AM200S |
|
Sample type |
Soft,hard,brittle and pasty |
|
Feed size |
＜15mm |
|
Finalfineness |
＜0.2-5μm（depending on the nature of the sample and the grinding environment） |
|
Feeding quantity |
10-200ml |
|
Setting grinding time |
1s-99h59min59s continuous |
|
Intermittent time |
1s-99h59min59s continuous |
|
Stop time |
1s-99h59min59s continuous |
|
Setting speed |
50rpm-150rpm,Section speed can be set |
|
Cycles |
1-20 times |
|
Parameter storage |
10 groups |
|
Load display |
Yes, Displayed on the LCD |
|
Sample temperature display |
Yes, Displayed on the LCD |
|
Grinding environment range |
Dry,Wet,Low temperature grinding in liquid nitrogen |
|
Mortar and pestle material |
Hard steel, stainless steel, Tungsten carbide , agate, Corundum, Zirconia, Hard porcelain |
|
Setting pestle pressure |
Pass the scale and display the pressure in the display |
|
Setting scraper peerssure |
Via knob |
|
W×H×D |
390mm×455mm×285mm |
|
Net weight |
40Kg |
|
Electrical parameters |
220V 250W |
